14 Vector Clocks

Lamport clock enforces a global total order, even if a and b are concurrent, there will still be timestamp where T(a) > T(b) or T(b) > T(a).

Vector clock acknowledges this downside, thus instead of global total order, enforces a partial casual order

v(a) = [x1, x2, x3, … xn]

• n, the # of processes in our system
• xj, the # of events that occured before a on process j

Vector Clock Process

Initially, v(a) = [0,0,0 … 0]

Three processes: P₁, P₂, P₃.

1. P₁: internal event → [1,0,0]

2. P₂: internal event → [0,1,0] (Both now independent — concurrent)

3. P₁ → P₂: sends a message with [1,0,0]
   P₂ receives it:
   Merge: max([0,1,0], [1,0,0]) = [1,1,0]
   Increment own entry: [1,2,0]
   So P₂’s vector now says: “I’ve seen 1 event from P₁, and 2 from myself.”


Vector timestamps are also comparable as follows:

Event p happened before Event q

if and only if:

• vp[i] ≤ vq[i] for all i
• there exist some k such that vp[k] < vq[k]

Happened-before

If v(a) < v(b), then a → b.
If a → b, then v(a) < v(b)

Concurrency

If v(a) !> v(b) and v(a) !< v(b)

Causally-Ordered Multicast

We don't have to guarantee that one event happens before another, unless they actually have a casual order. Use vector timestamps to acheive this.
